TT Custom Manufacturer 10mm 15mm 20mm 35mm 3.3V 5V 6V 12V Stepper Motor Mini Stepping Motor Micro Stepper Motor Dc Electric
1 / 5
TT Custom Manufacturer 10mm 15mm 20mm 35mm 3.3V 5V 6V 12V Stepper Motor Mini Stepping Motor Micro Stepper Motor Dc Electric
What are the main applications of the GM12-15BY DC gear motor?
This 15mm DC gear motor is ideally suited for devices that require small diameters, low noise operational levels, and large torque outputs, such as smart lock systems, miniature actuators, robotic joints, and precision medical equipment.
What range of reduction ratios are available for this motor model?
We offer a wide selection of reduction ratios including 3, 5, 10, 20, 30, 50, 60, 100, 150, 210, 250, 298, and 380 to meet your exact speed and torque needs.
What is the standard rated voltage and power requirements?
The GM12-15BY operates on a rated voltage of 5V DC. It features a resistance value of 10Ω and has a standard current flow of 500mA.
How much holding torque does the GM12-15BY provide?
Depending on the specific gear ratio, the holding torque ranges from 500g.cm (for the 1/30 ratio), 700g.cm (for the 1/50 ratio), up to 1050g.cm (for the 1/110 ratio).
What is the step angle of the GM12-15BY motor?
The motor is engineered with a standard step angle of 18 degrees, which delivers balanced control and high precision rotation performance.
